The SD20 sampling head is designed for low loss testing in applications such as microwave systems research and development, digital device charaterization and high speed digital communications circuit design.

For digital communications applications, the loop-through design of the Tektronix SD20 Single Channel High-performance Sampling Head permits viewing and triggering on the clock signal without the use of a power divider.

Some features of the Tektronix SD20
Sampling Head are:

• Bandwidth: 20GHz Max
• Form Factor: Plug-In
• Number of Channels: 1
• Single Channel
• Bandwidth of 20GHz Max
• Plug-In Form Factor
